10 / Selected work
Education assets · 3D
Technical CAD
High-precision 3D reconstructions of industrial systems for technical learning content.
03documented model views
3Dtechnical reconstruction
01readable assembly system
CADprecision-led workflow
Project overview
Complex machinery was reconstructed as precise, readable 3D assets for advanced technical education.
01 / Problem
Technical systems were visually dense
Industrial assemblies contain housings, connectors, modules, pipes, bolts and internal structures that are difficult to explain clearly with conventional source material.
02 / Solution
Reconstruct with educational clarity
I translated reference material into accurate hard-surface models, balancing technical detail with a visual hierarchy suitable for instructional sequences and close-up explanation.
03 / Outcome
Clear reusable learning assets
The resulting models improve technical communication and can be reused across course scenes, detail views and explanatory animations without rebuilding the underlying system.
